Aramid Fabrics

In a world where lightweight and durable composites are increasingly replacing traditional materials, Aramid plays an important role. Aramid Fibre also referred to as Kevlar® or Twaron is a man-made organic Polymer produced by spinning a solid fibre from a liquid chemical blend. The bright golden yellow filaments produced can have a range of properties, but all have high strength and low density giving very high specific strength.

The Benefits;

  • High Strength
  • Low Weight
  • Resistant to impact and abrasion damage
  • Can be waterproof
ARAMID FABRICS
Type Standard width Weight Weave Thread Count
fd/cm		 Construction Thickness Roll length
  cm g/m2   Warp  Weft Warp  Weft mm Linear meter
CMAT 170 100/127 170 Twill 2/2 5.1 5.1 1580 Dtex 1580 Dtex 0.18 100
CMA5S 205 100/127 205 5H Satin 6,2 6,2 1580 Dtex 1580 Dtex 0.20 100
CM B-AP 930 130 205 Plain 10.5 10.5 930 Dtex 930 Dtex 0.20 100
CM AT 310 100/127 310 Twill 4,5 4,5 3160 dtex 3160 dtex 0,4  100
CM B-AP 3360 130/150 460 Plain 6,7 6,7 3360 Dtex 3360 Dtex 0.40 50
CM AT 470 100/127 410 Twill 8,0 6,5 3160 dtex 3160 dtex 0,97 100
